基于CSS3和GSAP的超酷盒子爆炸动画特效

PetitQ 其他代码 2019-3-01 2.38K 0 1

这是一款使用 GSAP 的 TweenMax.js 和 CSS3 来制作的效果炫酷的盒子爆炸动画特效。该爆炸动画在用户点击页面中的一个弹跳的盒子的时候，盒子会爆炸为烟雾，然后会出现 SVG Logo，整个效果非常连贯逼真。

HTML 结构

该盒子爆炸效果的 HTML 结构如下：div.-box 是一个立方体盒子，div.explode 用于制作爆炸的烟雾效果。svg.icon 则是最后出现的 SVG Logo。

也想出现在这里？联系我们吧

```
<div class="-content -index">
```
```
  <div>
```
```
    <div class="bounce-wrap">
```
```
      <div class="bounce">
```
```
        <div class="-shadow"></div>
```

        <div class="-box-wrap js-box-wrap">

```
          <div class="-box">
```

            <div class="front wall"></div>

            <div class="back wall"></div>

            <div class="right wall"></div>

            <div class="left wall"></div>

```

```

            <div class="front-right wall"></div>

            <div class="front-left wall"></div>

            <div class="back-right wall"></div>

            <div class="back-left wall"></div>

```
          </div>
```
```
        </div>
```
```
        <div id="emitter"></div>
```
```
        <div class="explode">
```

          <span class="cloud -one js-cloud-1"></span>

          <span class="cloud -two js-cloud-2"></span>

          <span class="cloud -three js-cloud-3"></span>

```
        </div>
```

        <svg class="icon js-icon-logo" viewBox="0 0 162.5 47">

          <use xmlns:xlink="http://www.w3.org/1999/xlink" xlink:href="#logo_technology"></use>

```
        </svg>
```
```
      </div>
```
```
    </div>
```
```
      </div>
```
```
</div>
```

CSS 样式

在 CSS 样式中，主要是制作盒子的立方体效果，以及使用 CSS3 帧动画来制作盒子的弹性和阴影动画效果。盒子的弹性和阴影动画效果。

```
@-webkit-keyframes bounce {
```
```
  0% {
```
```
    -webkit-transform: translateY(0);
```
```
            transform: translateY(0);
```
```
  }
```
```
  100% {
```

    -webkit-transform: translateY(-25px);

            transform: translateY(-25px);

```
  }
```
```
}
```
```
@keyframes bounce {
```
```
  0% {
```
```
    -webkit-transform: translateY(0);
```
```
            transform: translateY(0);
```
```
  }
```
```
  100% {
```

    -webkit-transform: translateY(-25px);

            transform: translateY(-25px);

```
  }
```
```
}
```
```
@-webkit-keyframes shadow {
```
```
  0% {
```
```
    background: rgba(0, 0, 0, 0.5);
```

    -webkit-transform: scale(0.75) rotateX(75deg) rotateY(0deg) rotateZ(-45deg);

            transform: scale(0.75) rotateX(75deg) rotateY(0deg) rotateZ(-45deg);

    box-shadow: 0 0 0px rgba(0, 0, 0, 0.6);

```
  }
```
```
  100% {
```
```
    background: rgba(0, 0, 0, 0.15);
```

    -webkit-transform: scale(1) rotateX(75deg) rotateY(0deg) rotateZ(-45deg);

            transform: scale(1) rotateX(75deg) rotateY(0deg) rotateZ(-45deg);

    box-shadow: 0 0 10px rgba(0, 0, 0, 0.3);

```
  }
```
```
}
```
```
@keyframes shadow {
```
```
  0% {
```
```
    background: rgba(0, 0, 0, 0.5);
```

    -webkit-transform: scale(0.75) rotateX(75deg) rotateY(0deg) rotateZ(-45deg);

            transform: scale(0.75) rotateX(75deg) rotateY(0deg) rotateZ(-45deg);

    box-shadow: 0 0 0px rgba(0, 0, 0, 0.6);

```
  }
```
```
  100% {
```
```
    background: rgba(0, 0, 0, 0.15);
```

    -webkit-transform: scale(1) rotateX(75deg) rotateY(0deg) rotateZ(-45deg);

            transform: scale(1) rotateX(75deg) rotateY(0deg) rotateZ(-45deg);

    box-shadow: 0 0 10px rgba(0, 0, 0, 0.3);

```
  }
```
```
}
```

盒子的立方体效果：由于 IE 浏览器不支持 transform-style: preserve-3d;属性，所以在 IE 浏览器中看不到盒子的立体效果。

```
.bounce .-box {
```
```
  width: 32px;
```
```
  height: 32px;
```
```
  position: relative;
```
```
  -webkit-transform-style: preserve-3d;
```
```
          transform-style: preserve-3d;
```

  -webkit-transform: rotateX(-14deg) rotateY(-45deg) rotateZ(0deg);

          transform: rotateX(-14deg) rotateY(-45deg) rotateZ(0deg);

```
}
```
```
.bounce .-box .wall {
```
```
  width: 32px;
```
```
  height: 32px;
```
```
  position: absolute;
```
```
  -webkit-transition: all 1s ease-out;
```
```
  transition: all 1s ease-out;
```
```
  -webkit-backface-visibility: hidden;
```
```
          backface-visibility: hidden;
```
```
}
```
```
.bounce .-box .front {
```
```
  background: #f8f8fc;
```

  -webkit-transform: rotateX(0deg) rotateY(0deg) translateZ(16px) rotateX(90deg);

          transform: rotateX(0deg) rotateY(0deg) translateZ(16px) rotateX(90deg);

```
  -webkit-transform-origin: 50% 100%;
```
```
          transform-origin: 50% 100%;
```
```
  height: 50%;
```
```
  z-index: 1;
```
```
}
```
```
.bounce .-box .right {
```
```
  height: 32px;
```
```
  background: #f8f8fc;
```
```
  -webkit-transform-style: preserve-3d;
```
```
          transform-style: preserve-3d;
```

  -webkit-transform: translateX(16px) rotateY(90deg) rotateX(90deg);

          transform: translateX(16px) rotateY(90deg) rotateX(90deg);

```
  -webkit-transform-origin: 50% 100%;
```
```
          transform-origin: 50% 100%;
```
```
  height: 50%;
```
```
  z-index: 1;
```
```
}
```
```
.bounce .-box .back {
```
```
  background: #f8f8fc;
```

  -webkit-transform: rotateY(180deg) translateZ(16px) rotateX(90deg);

          transform: rotateY(180deg) translateZ(16px) rotateX(90deg);

```
  -webkit-transform-origin: 50% 100%;
```
```
          transform-origin: 50% 100%;
```
```
  height: 50%;
```
```
}
```
```
.bounce .-box .left {
```
```
  background: #f8f8fc;
```

  -webkit-transform: translateX(-16px) rotateY(-90deg) rotateX(90deg);

          transform: translateX(-16px) rotateY(-90deg) rotateX(90deg);

```
  -webkit-transform-origin: 50% 100%;
```
```
          transform-origin: 50% 100%;
```
```
  height: 50%;
```
```
}
```
```
.bounce .-box .front-left {
```
```
  background: #d1d5e9;
```
```
  height: 32px;
```

  -webkit-transform: rotateX(0deg) rotateY(0deg) translateZ(16px) translateY(16px);

          transform: rotateX(0deg) rotateY(0deg) translateZ(16px) translateY(16px);

```
  -webkit-transform-origin: 50% 100%;
```
```
          transform-origin: 50% 100%;
```
```
}
```
```
.bounce .-box .front-right {
```
```
  background: #96a0ce;
```
```
  height: 32px;
```

  -webkit-transform: translateX(16px) rotateY(90deg) translateY(16px);

          transform: translateX(16px) rotateY(90deg) translateY(16px);

```
  -webkit-transform-origin: 50% 100%;
```
```
          transform-origin: 50% 100%;
```
```
}
```
```
.bounce .-box .back-left {
```
```
  background: #b0c2d6;
```
```
  height: 32px;
```

  -webkit-transform: rotateX(0deg) translateX(-16px) rotateY(-90deg) translateY(16px);

          transform: rotateX(0deg) translateX(-16px) rotateY(-90deg) translateY(16px);

```
  -webkit-transform-origin: 50% 100%;
```
```
          transform-origin: 50% 100%;
```
```
}
```
```
.bounce .-box .back-right {
```
```
  background: #8a9fb4;
```
```
  height: 32px;
```

  -webkit-transform: rotateX(0deg) rotateY(180deg) translateZ(16px) translateY(16px);

          transform: rotateX(0deg) rotateY(180deg) translateZ(16px) translateY(16px);

```
  -webkit-transform-origin: 50% 100%;
```
```
          transform-origin: 50% 100%;
```
```
}
```

JavaScript

该特性依赖于 GSAP 的 TweenMax.js，使用时需要将其引入。

<script src="js/jquery.min.js"></script>

<script src='http://cdnjs.cloudflare.com/ajax/libs/gsap/1.18.0/TweenMax.min.js'></script>

该盒子爆炸动画特性的主要 JS 代码如下：

```
function init() {
```

  var emitter = document.getElementById("emitter"),

    container = document.createElement("div"),

```
    emitterSize = 100,
```
```
    dotQuantity = 50,
```
```
    dotSizeMax = 100,
```
```
    dotSizeMin = 10,
```
```
    speed = 1,
```
```
    gravity = 1;
```
```

```

  container.setAttribute("id", "emit-wrap");

  //setup the container with the appropriate styles

    container.style.cssText = "position:absolute; left:0; top:0; overflow:visible; z-index:5000; pointer-events:none;";

```
  document.body.appendChild(container);
```
```

```
```
  function createExplosion(container) {
```
```
    var tl = new TimelineLite({
```
```
      onComplete: function() {
```
```
        $('#emit-wrap').remove();
```
```
      }
```
```
    }),
```
```
      angle, length, dot, i, size;
```
```
    //create all the dots
```
```
    for (i = 0; i < dotQuantity; i++) {
```

      dot = document.createElement("div");

```
      dot.className = "emitter-dot";
```

      size = getRandom(dotSizeMin, dotSizeMax);

```
      container.appendChild(dot);
```

      angle = Math.random() * Math.PI * 2;

      length = Math.random() * (emitterSize / 2 - size / 2);

```
      TweenLite.set(dot, {
```
```
        x: Math.cos(angle) * length,
```
```
        y: Math.sin(angle) * length,
```
```
        width: size,
```
```
        height: size,
```
```
        xPercent: -50,
```
```
        yPercent: -50,
```
```
        force3D: true
```
```
      });
```

      //this is where we do the animation...

```
      tl.to(dot, 1 + Math.random(), {
```
```
        opacity: 0,
```

        x: Math.cos(angle) * length * 24,

        y: Math.sin(angle) * length * 24

```
      }, 0);
```
```
    }
```
```
    return tl;
```
```
  }
```
```

```
```
  function explode(element) {
```

    var explosion = createExplosion(container);

    // var bounds = element.getBoundingClientRect();

```

```
```
    var offset = $(element).offset();
```
```
    var width = $(element).width();
```
```
    var height = $(element).height();
```
```

```
```
    // TweenLite.set(container, {
```

    //     x: bounds.left + bounds.width / 2,

    //     y: bounds.top + bounds.height / 2

```
    // });
```
```
    TweenLite.set(container, {
```
```
      x: offset.left + width / 2,
```
```
      y: offset.top + height / 2
```
```
    });
```
```
    explosion.restart();
```
```
  }
```
```

```
```
  function getRandom(min, max) {
```

    return min + Math.random() * (max - min);

```
  }
```
```

```

  emitter.onmousedown = emitter.ontouchstart = function() {

```
    explode(emitter);
```
```
    $(emitter).hide();
```
```

```
```
    $('.-shadow').hide();
```
```
    $('.js-box-wrap').hide();
```
```
    setTimeout(function(){
```
```
      $('.js-trigger-reset').css({
```
```
        'display': 'inline-block'
```
```
      });
```
```
    }, 2000);
```
```

```
```

```
```
    var tl = new TimelineMax();
```
```
    tl.add("logo")
```
```
    .add(logoReveal,"logo");
```
```
  }
```
```
}
```
```

```
```
function logoReveal() {
```
```
  var logoReveal = new TimelineMax();
```
```

```

    logoReveal.to('.js-icon-logo', 1, {autoAlpha: 1, ease: Power4.easeOut});

```

```
```
    return logoReveal;
```
```
}
```
```

```
```
function reset() {
```
```
  $('.-shadow').attr('style', '');
```
```
  $('.js-box-wrap').attr('style', '');
```
```
  $('.js-icon-logo').attr('style', '');
```
```
  $('#emitter').attr('style', '');
```
```
  $('.js-trigger-reset').hide();
```
```
}
```
```

```
```
$(document).ready(function () {
```
```
  init();
```

  $('.js-trigger-reset').click(function() {

```
    reset();
```
```
    init();
```
```
  });
```
```
});
```
